Japanese excavators and loaders rarely use an engine of their own brand. Kobelco uses Hino, Isuzu and Yanmar engines; Hitachi uses Isuzu and Cummins; Takeuchi uses Kubota, Yanmar and Isuzu; Komatsu builds its engines with Cummins. So the first question for any of these machines is not "which excavator" but "which engine" - the answer gives you the ECU family. This guide maps it brand by brand.
Key facts
- Kobelco - 48 versions: Hino engines on Denso SH7058 (SK170-SK500), Yanmar engines on Bosch EDC17CV54 (SK55-SK140), Isuzu on Transtron (SK130 / SK140).
- Hitachi - 96 versions: Isuzu engines on Transtron (ZX excavators), Cummins CM2350 (ZW loaders), Bosch EDC17CV52 (ZX-W wheeled).
- Takeuchi - 32 versions: Bosch EDC17CV52 / CV54 (TB excavators), Denso SH7058 / SH7254x / R5F72546R (TL track loaders), Transtron (TB1140 / TB295).
- Komatsu - 178 versions: Cummins CM2350 / CM2250 / CM850 and Bosch EDC17CV41 / CV44 / CV54.
- Yanmar - 33 versions: Bosch EDC17CV54 on most Tier 4 final engines, Denso SH7058 on others.
- Typical prices: Transtron DPF 85 EUR / EGR 70 EUR / AdBlue 190 EUR; Denso SH7058 105-120 / 95 / 200-220 EUR; Cummins CM2350 140 / 95 / 290 EUR; Stage 1 95-160 EUR.
Brand by brand
Kobelco
| Models | Engine | ECU | Versions | DPF / EGR / AdBlue / Stage 1 |
|---|---|---|---|---|
| SK170, SK210, SK235, SK260, SK300, SK350, SK500, SK1100G; New Holland E385C / E485C | Hino J05E 5.1, J08E 7.7, P11C 10.5 | Denso SH7058, SH7059; 1N83M on the newest SK170 / SK260 | 33 | 105 / 95 / 200 / 160 EUR |
| SK55, SK85, SK125, SK140, SK146, ED160 | Yanmar 2.2-3.3 | Bosch EDC17CV54 | 9 | see the price list |
| SK130, SK135, SK140, ED160 | Isuzu 4JJ1 3.0 | Transtron 4Jxx / 4JJ1 | 6 | 85 / 70 / 190 / 120 EUR |
| SK170-SK295 (older) | 3.3 L | Bosch EDC7UC31 | price list | AdBlue 180 / Stage 1 120 EUR |
Hino-engined Kobelcos can also be modified through Hino's dealer tool - see Hino DX3 dealer files.
Hitachi
| Models | Engine | ECU | DPF / EGR / AdBlue / Stage 1 |
|---|---|---|---|
| ZX130-ZX160 | Isuzu 4JJ1 3.0 | Transtron 4JJ1 / 4Jxx | 85 / 70 / 190 / 120-140 EUR |
| ZX135US-7 | Toyota 1KD 3.0 | Denso 276122-6460 | 90 / 85 / - / 120 EUR |
| ZX180-ZX250 | Isuzu 4HK1 5.2 | Transtron 4HK1 | 85 / 70 / 190 / 120-140 EUR |
| ZX290-ZX350 | Isuzu 6HK1 7.8 | Transtron 6HK1 | 85 / 70 / 190 / 120-140 EUR |
| large ZX | Isuzu 6UZ1 9.8, 6WG1 15.7 | Transtron 6UZ1, 6WG1 | 85 / 70 / 190 / 120-140 EUR |
| ZW180-ZW370 wheel loaders | Cummins QSB6.7, QSL9 | Cummins CM2350 / CM2350A | 140 / 95 / 290 / 160 EUR |
| ZX145W and other wheeled | 4.1 L | Bosch EDC17CV52 | 220 / 90 / 180 / 140 EUR |
There is no "Hitachi ECU" on these machines - the engine decides. The same Transtron files logic applies to CASE, Link-Belt, Sumitomo, Hidromek and John Deere G-series excavators with Isuzu engines.
Takeuchi
| Models | ECU | Versions | DPF / EGR / AdBlue / Stage 1 |
|---|---|---|---|
| TB2150, TB2150R, TB2160, TB295W | Bosch EDC17CV52 | 10 | see the price list |
| TB250, TB260, TB280, TB290, TL260 | Bosch EDC17CV54 | 8 | see the price list |
| TL8, TL10, TL12, TL12V2, TL127, TL150, TCR50 | Denso SH7058, SH7254x, R5F72546R, SH72543, SH72546R | 11 | 120 / 95 / 220 / 160 EUR |
| TL6R (Kubota V2403) | Bosch EDC17C55 / EDC17CV45 | 1 | 120-140 / 95-105 / - / 140 EUR |
| TB1140, TB295 (Isuzu 3.0) | Transtron | 2 | 120 / 85 / 190 / 95 EUR |
| TL8R 2.6 | Denso 1E785-59052 | price list | 180 / 120 / 340 / 160 EUR |
Komatsu
Komatsu engines (SAA4D95, SAA4D107, SAA6D107, SAA6D114, SAA6D125, SAA6D140, SAA6D170) come from the Komatsu-Cummins partnership:
| Machines | ECU | DPF / EGR / AdBlue / Stage 1 |
|---|---|---|
| PC138-PC490, PW118 / PW140, D39 / D51 / D65, WA270-WA600 | Cummins CM2350 / CM2350A | 140 / 95 / 290 / 140 EUR |
| PC210-PC490 (8.3 / 8.9 / 15.0 L) | Cummins CM2250, CM850 | 105-120 / 85-95 / 180 / 140-160 EUR |
| D65-D475 dozers, Komatsu Forest forwarders and harvesters | Bosch EDC17CV41, EDC17CV44, EDC17CV54 | 120-180 / 85 / 150 / 120 EUR |
| WB93 backhoe loaders | Bosch EDC17C49, MD1CS069 / MD1CC878 | 120 / 85-95 / 190-205 / 105-160 EUR |
Forestry machines are covered in detail in our Komatsu Forest article.
Yanmar
Yanmar's own Tier 4 final engines (3TNV / 4TNV, 1.6-3.3 L) are mostly on Bosch EDC17CV54 - 21 of our 33 Yanmar versions: SV and ViO excavators, Mustang loaders, forklifts. Older and some Asian-market models (YT / YH tractors, SV) use Denso SH7058; the bigger SV120 / TW110 use EDC17CV52. Prices: Denso 120 / 95 / 220 / 160 EUR, EDC17CV54 180 / 85 / 150 / 120 EUR. Yanmar track dumpers often have a separate AdBlue DCU - send both reads.
Sumitomo, Kato, Tadano
- Sumitomo SH210 / SH350 - Cummins QSB6.7 / QSL9 on CM2350 (140 / 95 / 290 / 140 EUR); H330 with Isuzu 6HK1 on Transtron (85 / 70 / 190 / 95 EUR). Sumitomo designs are also sold as Link-Belt and some CASE models.
- Kato - HD513 / HD514 (Isuzu 4JJ1, Transtron), HD820 / HD870 (Isuzu 4HK1, Transtron), SR250 / CR130 (Denso SH7058), IC120 (Cummins CM2350).
- Tadano cranes - Cummins CM2350.
What we do on these machines
- DPF, EGR and AdBlue off - the soot counter and service regeneration request are disabled together with the filter. On Stage V machines with a separate AdBlue DCU, send both reads.
- Stage 1 / ECO - more hydraulic torque or lower consumption per hour.
- Selective DTC off - from 50 EUR; you give the codes, we disable exactly those.
- Reading: Alientech KESS3 and K-TAG, New Genius, Magic FLEX, CMD, FGTech, PCMflash and similar tools, on the bench or in boot mode depending on the unit.
- In the order form pick the machine brand (Kobelco, Hitachi, Takeuchi, Komatsu, Yanmar, Sumitomo, Tadano) and the ECU type.
FAQ
How do I know which engine my excavator has?
The engine plate on the block, the machine's spec sheet, or the ECU label - Transtron means Isuzu, a Denso with a Hino software number means Hino, Bosch EDC17CV54 on a small Kobelco or Takeuchi usually means Yanmar.
Is a Hitachi ZX210 file the same as a CASE CX210?
Both use an Isuzu 4HK1 and a Transtron ECU, but the calibrations differ. Send the read from the machine itself.
My Komatsu has a Cummins ECU. Is that normal?
Yes. Komatsu engines are built with Cummins and use Cummins CM2350, CM2250 or CM850 control units - or Bosch EDC17 on dozers and forestry machines.
Ready to order? Go to fs.auto-remap.com, pick the machine brand and your ECU type.
