Isuzu builds trucks, but even more Isuzu engines go into machines that carry other names. The 4HK1 and 6HK1 in an Elf or Forward are the same engines that power Hitachi, CASE, Link-Belt and Sumitomo excavators - and all of them are controlled by Transtron, Isuzu's own electronics company. Add the Denso units on older and newest trucks and the Bosch units on Euro 6 models, and you have the full picture of this guide.
Key facts
- 171 software versions published on /solutions/make/isuzu/ - about 107 of them Transtron.
- Transtron by engine: 4HK1 5.2, 4Jxx / 4JJ1 3.0, 6HK1 7.8, 6UZ1 9.8, 6WG1 15.7.
- Denso: SH7058 / SH7059 on 2003-2015 N- and F-series, SH72546 on 2008+ NPR / NQR, Gen2 1N83M on the newest.
- Bosch: EDC17CV41 (NPR / NQR 3.0 from 2013), MD1CC878 (Elf, Forward, Giga 2020+), MD1CE108 (Giga 9.8 / 15.6).
- Prices: Transtron - DPF 85 EUR, EGR 70 EUR, AdBlue 190 EUR, Stage 1 95-140 EUR; Denso SH7058 / SH7059 - 105 / 95 / 190 / 140 EUR; Denso 1N83M - 160 / 105 / 270 / 160 EUR; Bosch EDC17CV41 - 105 / 70 / 150 / 120 EUR.
Which ECU is in your Isuzu truck
| Range | Engines | ECUs | Versions |
|---|---|---|---|
| Elf / N-series - NPR, NQR, NPS, NMR, NRR, N75, P75, Grafter | 4JJ1 3.0, 4HK1 5.2 | Transtron 4HK1 / 4Jxx / 4JJ1 / SH725x; Denso SH7058, SH7059, SH72546, 1N83M; Bosch EDC17CV41, MD1CC878 | 83 |
| Forward / F-series - FRR, FSR, FTR, FVR, F110 / F14 | 4HK1 5.2, 6HK1 7.8 | Transtron 4HK1 / 6HK1 / SH7055; Denso SH7058, SH7254x, 1N83M; Bosch MD1CC878; Cummins CM2450A (FTR 6.7) | 27 |
| Giga / FX / C-series / EXZ | 6UZ1 9.8, 6WG1 15.7, 14.2 | Transtron 6WG / 6WG1 / 6UZ1 / SH72544; Bosch MD1CE108, MD1CC878 + Continental ACM; Denso SH7055 | 25 |
| Buses - Novo, Visigo, Citibus | 3.0, 5.2, Cummins 4.5 / 6.7 ISB | Transtron, Denso SH7059, Cummins CM2350 / CM2350A | 6 |
| Isuzu-built for others - GMC / Chevrolet W-series, Mazda Titan, Nissan Atlas | 4HK1 5.2, 4JJ1 3.0 | Denso SH7058, Transtron | price list |
Year is a poor guide: an NPR from the same period can carry a Transtron, a Denso SH72546 or a Bosch EDC17CV41 depending on market and emission level. The label or your tool decides; then search the software number in our Isuzu list. Pickups (D-Max, MU-X - another 21 versions) are covered in the pickups guide.
Isuzu engines in excavators and machines
Every machine with an Isuzu engine runs a Transtron - the calibration is the machine maker's, the ECU family and our method are the same:
| Engine | Machines |
|---|---|
| 4JJ1 3.0 | Hitachi ZX130-ZX160, CASE CX130-CX160, Kobelco SK130 / SK140, Sany SY135C / SY155U, John Deere 135G, Takeuchi TB1140, Kato HD513 / HD514 |
| 4HK1 5.2 | Hitachi ZX180-ZX250, CASE CX210 / CX250, Link-Belt 210X / 250X, Hidromek, JCB JS200, Kato HD820 / HD870, gensets |
| 6HK1 7.8 | Hitachi ZX290-ZX350, CASE CX300 / CX350, Link-Belt 350, JCB JS360, Sumitomo, 180 kVA gensets |
| 6UZ1 9.8 / 6WG1 15.7 | large Hitachi ZX, CASE CX470 / CX500, John Deere 470G / 670G |
What we do on Isuzu
| Solution | On Isuzu | Price |
|---|---|---|
| DPF off | Regeneration, soot model and counter off, parked-regeneration request removed, DPF monitoring disabled. The N-series in city work is the classic case. | 85 EUR (Transtron) - 105 EUR (Denso) - 160 EUR (1N83M, MD1CC878) |
| EGR off | Valve closed in software with monitoring off. | 70-105 EUR |
| AdBlue / SCR off | On Euro 6 Elf, Grafter, newer N- and F-series and Giga. Several of these have a separate AdBlue unit (DCU / ACM) - Grafter and Giga in particular - so send both reads. | 150-290 EUR |
| Stage 1 / ECO | More torque for loaded delivery and tipper work, or an economy map for fleets. | 95-160 EUR |
| Selective DTC off | We decoded the Transtron fault-code tables ourselves - six parallel tables per code - so a code is switched off in each of them, including the enable switch, not only hidden. | from 50 EUR |
Typical requests: Elf and NPR / NQR - DPF, EGR and AdBlue off with the soot counter; Grafter - AdBlue module off; Forward 4HK1 - DPF and EGR off with Stage 1; specific codes such as P0382 or P2902 off on request. Clear stored DPF and AdBlue faults and inducement countdowns before writing.
Reading and ordering
- Tools: Alientech KESS3 and K-TAG, New Genius, Magic FLEX, CMD, FGTech, PCMflash and other common tools. Transtron and Denso units read on the bench or in boot mode depending on type; ask us if unsure.
- In the order form choose Isuzu and the range (Elf, NPR, NQR, NPS, Forward, Giga, Novo Citi, Visigo), the engine and the ECU type. For an excavator with an Isuzu engine, choose the machine brand (Hitachi, CASE, Link-Belt, Kobelco) and the Transtron entry.
- Stock and Stage 1 figures for the N-series are in our tuning catalog.
FAQ
Transtron or Denso - how do I tell on an Isuzu?
The label names the maker. Without it, your tool reports the ECU type once connected. Both are covered; prices differ, so pick the matching entry.
My Grafter / Giga has a separate AdBlue unit. Do you need it?
Yes - for AdBlue off send both the engine ECU read and the AdBlue module read.
Is the 4HK1 in my Hitachi excavator the same as in an Isuzu truck?
Same engine, same Transtron family, different calibration. Send the excavator's read and pick Hitachi in the order form.
Can you switch off just one code?
Yes. Give us the code (P-code or SPN / FMI); we disable exactly that one, in every table that holds it.
Ready to order? Go to fs.auto-remap.com, pick Isuzu (or the machine brand) and your ECU type.
