The Hilux, the Land Cruiser, the D-Max, the L200 and the Navara are the work trucks of half the world - mines and farms in Africa, contractors in the Middle East, stations in Australia, fleets in Latin America. Most of them run Japanese electronics: Denso on Toyota and Mitsubishi, Transtron on the Isuzu 3.0, with Bosch and Continental on some engines. This guide shows which unit you have and what it costs.
Key facts
- Toyota D-4D (Hilux, Land Cruiser 200 / Prado, Fortuner, HiAce): Denso with NEC processors, and from about 2015 Denso Gen3 RH850 (R7F701202 / R7F701216).
- Isuzu D-Max / MU-X: Transtron on the 2.5 and 3.0 (4JK1, 4JJ1, 4JJ3 - TC265 on 2019+), Bosch EDC17C83 / MD1CS089 / MD1CS018 on the 1.9 - 21 versions.
- Mitsubishi L200 / Triton / Pajero: Denso SH7058, SH7059, SH7254x / SH725x - 23 versions.
- Nissan Navara / Patrol: Denso SH7058 / SH7059 on the D40 2.5 dCi, Bosch EDC17C42 and Continental SID310 / SID321 on the D23.
- Mazda BT-50: from 2020 the Isuzu 3.0 4JJ3 on Transtron; earlier the Ford-based 2.2 / 3.2 on Bosch and Continental.
- Prices: Toyota - DPF 80 EUR, EGR 70 EUR, AdBlue 150 EUR, Stage 1 95-105 EUR; Isuzu Transtron - 85 / 70 / 190 / 85-105 EUR; Mitsubishi Denso - 85-95 / 70-95 / 190 / 95 EUR.
Which ECU is in your pickup
| Model | Engines | ECU | DPF / EGR / AdBlue / Stage 1 |
|---|---|---|---|
| Toyota Hilux N70 (2005-2015) | 2.5 / 3.0 D-4D (2KD, 1KD), 2.4 / 2.8 | Denso NEC, NEC Gen.3 | 80 / 70 / 150 / 95-105 EUR |
| Toyota Hilux 2015+, Fortuner 2020+, Prado 2021+ | 2.4 / 2.8 D-4D (2GD, 1GD) | Denso Gen3 R7F701202 / R7F701216 | 80 / 70 / 150 / 105 EUR |
| Toyota Land Cruiser 200 (2007-2021) | 4.5 V8 D-4D (1VD), 2.8 / 3.0 / 3.3 | Denso NEC, NEC Gen.3 | 80 / 70 / 150 / 95-105 EUR |
| Toyota HiAce, Fortuner (2004+) | 2.5 / 3.0 D-4D | Denso NEC, Gen3 | 80 / 70 / 150 / 95-105 EUR |
| Isuzu D-Max 2003-2020, MU-X | 2.5 4JK1, 3.0 4JJ1 | Transtron 4Jxx / 4JJ1; Denso SH7059 on some 3.0 | 85 / 70 / 190 / 85 EUR |
| Isuzu D-Max 2019+, MU-X 2020+ | 3.0 4JJ3, 2.5 | Transtron TC265 (4JJ3) | 85 / 70 / 190 / 105 EUR |
| Isuzu D-Max / MU-X 1.9 | 1.9 RZ4E, 2.2 | Bosch EDC17C83, MD1CS089, MD1CS018 | 80-110 / 75-85 / 190-240 / 105-120 EUR |
| Mitsubishi L200 / Triton (KA / KB) 2005-2015 | 2.5 DI-D 4D56, 3.2 DI-D | Denso SH7058 / SH7059; older "Denso old type"; Bosch EDC16CP31 on some 2.5 | 85 / 70 / - / 95 EUR |
| Mitsubishi L200 / Triton Euro 6 | 2.3 / 2.4 DI-D | Denso SH725x / SH7254x | 95 / 85-95 / 190 / 95 EUR |
| Mitsubishi Pajero V80 (2006-2021) | 3.2 DI-D | Denso SH7058 / SH7059 | 85 / 70 / - / 95 EUR |
| Nissan Navara D40, NP300, Patrol Y61 | 2.5 dCi YD25 | Denso SH7058 / SH7059 | 85 / 70 / - / 95 EUR |
| Nissan Navara D23 (2014+) | 2.3 dCi | Bosch EDC17C42, Continental SID310 / SID321 | 65-95 / 60-80 / 150-190 / 95-140 EUR |
| Mazda BT-50 2020+ | 3.0 4JJ3 (Isuzu) | Transtron TC265 | 85 / 70 / 190 / 105 EUR |
Click the model name for stock and Stage 1 power figures in our tuning catalog. Toyota pickups are not yet in our solutions database by software number - order them directly in the file service under Toyota and the ECU type.
What workshops order
- Toyota Hilux 2.4 / 2.8 GD and Land Cruiser: AdBlue off on Euro 6 versions, DPF and EGR off, Stage 1. Land Cruiser 200 4.5 V8 - DPF, EGR and AdBlue together.
- Isuzu D-Max: DPF and EGR off, AdBlue off on 2019+ (on some versions the AdBlue unit is separate - send both reads), Stage 1.
- Mitsubishi L200 / Triton: DPF and EGR off, AdBlue on Euro 6.
- Nissan Navara: EGR off, DPF off, "back to original" after another provider's file.
Stage 1 on a pickup that tows: say so in the order, together with the gearbox type - we take the load and the drivetrain into account when we build the file.
Reading and ordering
- Tools: Alientech KESS3 and K-TAG, New Genius, Magic FLEX, CMD, FGTech, PCMflash and other common tools. Older units often read over OBD; Toyota Gen3, Transtron TC265 and Euro 6 units may need bench or boot access depending on the tool.
- In the order form choose the brand (Toyota, Isuzu, Mitsubishi, Nissan, Mazda), the model, the engine and the ECU type.
FAQ
My Hilux shows "Denso" in the tool. NEC or Gen3?
Roughly, models before 2015 with the KD engines are NEC, the 2GD / 1GD engines from 2015 are Gen3 (RH850). The tool or the label confirms it; the price differs by 10 EUR on Stage 1.
Is the BT-50 3.0 the same as the D-Max?
Since 2020, yes: the BT-50 uses Isuzu's 3.0 4JJ3 with a Transtron ECU. Older BT-50s are Ford Ranger-based with Bosch or Continental units.
Can you return my Navara to stock after another provider's file?
Yes, if you have the original read. Otherwise send what is in the car and we will tell you what can be restored.
Ready to order? Go to fs.auto-remap.com, pick the brand, model and ECU type.
File service for professional tuners and workshops.
Prices are indicative and taken from our current price list. Emission-related modifications are supplied for off-road, motorsport, export and research use only, in territories where such modification is permitted. It is the customer's responsibility to comply with local legislation.
