Foton is a Cummins truck with a Chinese badge. Beijing Foton Cummins (BFCEC) builds the ISF2.8 and ISF3.8 four-cylinders that power the Aumark and Tunland, and the ISG11 / ISG12 big sixes that power the Auman GTL and ETX. On the export heavy range you will also find the Cummins X12. That means the control units are the same CM families we have been working on for years on American Cummins trucks - CM2220, CM2150, CM2880 and CM2670 - with a handful of Bosch units on the lighter and newer models.
Key facts
- 95 software versions published on /solutions/make/foton/ - the largest Chinese truck brand in our database.
- Brand in the file service: Foton - the whole range, including the ISG-engined Auman and the bus and coach chassis, sits under that one entry.
- Aumark, Tunland, Terracota, View (ISF2.8 / ISF3.8): Cummins CM2220 / CM2220A / CM2220C - 45 versions.
- Auman GTL / ETX / TL / EST-A (ISG11, ISG12, 6.7-12 L): Cummins CM2880, CM2150C / CM2150E.
- Auman export with X12 / 12.9 L: Cummins CM2670 / CM2670E.
- Bosch units: MD1CS089 (Miler, Sauvana, View), EDC17CV44 and CV54 (Auman 10-12 L), EDC17C81 / EDC17C55 (Tunland G7, Auman 2.8), MD1CC878 (Aoling MRT), EDC7UC31 (Auman ETX B290W).
Which ECU is in your Foton
| Models | Engines | ECU | Versions |
|---|---|---|---|
| Aumark, Tunland, Terracota, View, FT500, K1, pickups | Cummins ISF2.8 110-161 hp, ISF3.8 154-158 hp, 4.5 L 185 hp | Cummins CM2220C, CM2220, CM2220A | 45 |
| Auman GTL, Auman ETX / ETS / TL / TX, Auman EST-A, Golden Dragon chassis | ISG11 10.5 L, ISG12 11.8 L 350 hp, 8.9 L 335-340 hp, 6.7 L 210 hp, 12.0 L | Cummins CM2880 / CM2880A, CM2150C / CM2150E | 20 |
| Auman export, Auman A13, Auhawk, Galaxy | Cummins X12 11.9 L, 12.9 L 420-550 hp, 10.5-14.5 L | Cummins CM2670 / CM2670E | 12 |
| Auman (10-12 L range), Auman 1839 | 10-12 L 330-460 hp, 10.8 L 385 hp, 6.0 L 228 hp | Bosch EDC17CV44 / CV41 / CV54, Cummins CM876 | 4 |
| Miler, Sauvana, View, Aumark, Aucan, BJ1078, Tunland G7 | 2.0-2.5 TDI, 3.8 TDI | Bosch MD1CS089, MD1CE108, EDC17C81, EDC17C55 | 8 |
| Tunland (petrol), View, View C2 | 2.0 L turbo 188 hp, 1.5-2.4 16V | Bosch MED17.8.10, MED17.8.10.1, ME17.8.8 | 6 |
What we can do, and what it costs
| Solution | CM2220 (ISF) | CM2150C/E (ISBe/ISLe) | CM2880 (ISG) | CM2670 (X12) | MD1CS089 |
|---|---|---|---|---|---|
| DPF / DOC off | 105 EUR | 105 EUR | 140 EUR | 190 EUR | 95-105 EUR |
| EGR off | 85 EUR | 85 EUR | 105 EUR | 120 EUR | 75-85 EUR |
| AdBlue / SCR off (or reduction) | 180 EUR | 170 EUR | 240-280 EUR | 320 EUR | 190-240 EUR |
| Stage 1 or ECO file | 140 EUR | 140 EUR | 140 EUR | 140 EUR | 120 EUR |
| Stage 1+ / Stage 2 | 210 EUR | 210 EUR | - | - | 180 EUR |
| Throttle valve / swirl flaps | 105 EUR | 95-105 EUR | 105 EUR | 105 EUR | 70 EUR |
| Selective DTC off | 50-60 EUR | 60 EUR | 50-60 EUR | 50 EUR | 50 EUR |
| Checksum / back to original | 40 / 80 EUR | 40 / 80 EUR | 80 / 80 EUR | 80 / 80 EUR | 15 / 30 EUR |
Reading and ordering
- Find the engine first. ISF2.8 / ISF3.8 means CM2220-family; ISG11 / ISG12 means CM2880; X12 means CM2670. The Cummins ECU label carries the part number and the calibration.
- Read it. Cummins units are usually handled with Calterm-type tooling and produce .xcal files - send the file exactly as the tool wrote it. Autotuner, KESS3 and PCMtuner also cover many of them; the Bosch units read on bench or boot.
- Mind the checksum and CVN. On Cummins this is where jobs go wrong. We handle it, but do not re-pack the file yourself afterwards.
- Order at fs.auto-remap.com under Foton, pick the model, engine and ECU type, upload the read and tick the options.
FAQ
Is a Chinese Cummins ISF the same as the ones in Europe and the US?
The ISF2.8 and ISF3.8 built by Beijing Foton Cummins use the same CM2220 control-unit family as other Cummins applications, with the same tooling, checksum and CVN handling. The calibrations are Foton-specific, which is why we keep a per-version database.
What is the difference between CM2880 and CM2670 on an Auman?
CM2880 is the ISG11 / ISG12 unit (10.5 and 11.8 L); CM2670 is the X12 / X13 export unit (11.9-13.5 L). Different price lines - CM2670 AdBlue off is 320 EUR against 240-280 EUR on CM2880.
Can you do just an economy file without touching emissions?
Yes. The Stage 1 position also covers ECO files: same price, different target. Say "ECO" in the order comment. On fleets we often combine an ECO map with EGR off only, leaving DPF and SCR in place.
Are the Foton bus and coach chassis listed too?
They are. The ISG11 and ISG12 bus and coach chassis sit under Foton - and under Higer and Yutong as well, because the file is the same for all three. Pick the ISG line that matches your engine, or send the read and we will point you at it.
Ready to order? Go to fs.auto-remap.com, pick Foton and your Cummins or Bosch ECU.
